■ Class D amplifier: Max Power up to 1300W @ 1Ω.
■ All-MOSFET DC-DC PWM power supply design.
■ Double-sided FR-4 PCB for sturdy structure and strong anti-interference capability.
■ Multiple protection functions for safety and stability.
■ Brushed finish, precision-machined aluminum alloy housing.
■ Compact size for easy installation.
■ Low heat generation, high energy efficiency – especially suitable for new energy vehicles.
| Model: |
FC-1 V2 |
| Type: |
Class D Mono Channel Amplifier |
| Max Power @ 1Ω: |
1300 W |
| Nom Power @ 1Ω: |
1000 W |
| Max Power @ 2Ω: |
870 W |
| Nom Power @ 2Ω: |
600 W |
| Max Power @ 4Ω: |
600 W |
| Nom Power @ 4Ω: |
400 W |
| Operating Voltage : |
10 - 16 VDC |
| Freq. Resp. Range: |
10 Hz - 400 Hz |
Low-Pass Direct Adju. Range:
|
10 Hz - 50 Hz |
| Low-Pass Freq. Adju. Range: |
52 Hz - 400 Hz |
| Signal Noise Ratio: |
≥90 dB |
| Input Sensitivity: |
0.55V ~ 5V |
| Low-Pass Gain: |
0 - 12 dB |
| Input Impedance: |
20k Ω |
| T.H.D.: |
0.1 % |
| Weight: |
1.77 kg |
| Dimensions (LxWxH): |
226 x 126 x 50 mm |
