| ■ 4-channel 110W output ■ Class-D amplifier topology for high-efficiency operation ■ Supports high-pass, low-pass filter adjustments, and bypass adjustments ■ Closed-loop power supply design, output power unaffected by supply voltage ■ Advanced anti-reverse power supply line design to prevent damage from incorrect wiring ■ Automatic overload protection (automatic recovery after elimination), preventing distortion and damage to speakers and amplifiers ■ Comprehensive protection features for safety and stability |
| Model: | FC-4 |
| Type: | Class D Four Channels Amplifier |
| Max Power @ 4Ω: | 110 W x 4 ch |
| Nom Power @ 4Ω: | 75 W x 4 ch |
| Supply Voltage: | 11 - 15 VDC |
| Freq. Resp. Range (-3db): | 10 Hz - 20k Hz |
| Hi-pass Adjustment Range: | 50 Hz - 250 Hz |
| Low-pass Adjustment Range: | 50 Hz - 250 Hz |
| Signal Noise Ratio: | 95 dB |
| Input Impedance: | 10K Ω |
| Input Sensitivity: | 0.48 V - 2 V |
| Degree Of Loss Of Truth: | ≤0.01% |
| Power Supply Voltage Range: | 8 - 18 VDC - 1mA |
| Weight: | 1.25 kg |
| Dimensions (LxWxH): | 204 x 126 x 49.5 mm |
