■ Class D amplifier: Total Max Power 1120W.
■ Supports bridged mode for effortless control of high-power subwoofers.
■ All-MOSFET DC-DC PWM power supply design.
■ Double-sided FR-4 PCB for sturdy structure and strong anti-interference capability.
■ Multiple protection functions for safety and stability.
■ Brushed finish, precision-machined aluminum alloy housing.
■ Compact size for easy installation.
■ Low heat generation, high energy efficiency – especially suitable for new energy vehicles.
| Model: |
FC-4 V2 |
| Type: |
Class D Four Channels Amplifier |
| Max Power @ 2Ω: |
280 W x 4 ch |
| Nom Power @ 2Ω: |
220 W x 4 ch |
| Max Power @ 4Ω: |
150 W x 4 ch |
| Nom Power @ 4Ω: |
120 W x 4 ch |
| Bridge Max Power @ 4Ω: |
560 W x 2 ch |
| Bridge Nom Power @ 4Ω: |
440 W x 2 ch |
| Operating Voltage : |
10 - 16 VDC |
| Freq. Resp. Range: |
20 Hz - 20 kHz |
| Signal Noise Ratio: |
≥90 dB |
| Input Sensitivity: |
0.55V ~ 7V |
| Input Impedance: |
20k Ω |
| T.H.D.: |
0.1 % |
| Weight: |
1.76 kg |
| Dimensions (LxWxH): |
226 x 126 x 50 mm |
