■ 2-Ohm Class-D Full-Range Digital Stereo Sound
■ Features a new low-heat circuit
■ 4/3/2 channel design
■ Full field-effect tube DC pulse width modulation power supply
■ Comprehensive protection circuit
■ Uses double-sided FR-4 material
■ Features 4GUAGE nickel-plated speaker output terminals
■ Adopts an ultra-compact size design
| Model: |
FD-4 V2 |
| Type: |
Class D Four Channels Amplifier |
| Max Power @ 2Ω: |
360 W x 4 Ch |
| Nom Power @ 2Ω: |
180 W x 4 Ch |
| Max Power @ 4Ω: |
240 W x 4 Ch |
| Nom Power @ 4Ω: |
120 W x 4 Ch |
| Bridge Max Power @ 4Ω: |
720 W x 2 Ch |
| Bridge Nom Power @ 4Ω: |
360 W x 2 Ch |
| Freq. Resp. Range (-3db): |
10 Hz - 50k Hz |
| Hi-pass Freq. Adjustment Range: |
50Hz - 250 Hz |
| Low-pass Adjustment Range: |
50Hz - 250 Hz |
| Signal Noise Ratio: |
93 dB |
| Degree Of Loss Of Truth: |
<0.05% |
| Weight: |
1.62 kg |
| Dimensions (LxWxH;mm): |
248 x 125 x 48.5 |
