■ 4-channel 150W output
■ Class-D amplifier topology for high-efficiency operation
■ Supports high-pass, low-pass filter adjustments, and bypass adjustments
■ Closed-loop power supply design, output power unaffected by supply voltage
■ Compact size, full aluminum body for excellent heat dissipation
■ Comprehensive protection features for safety and stability
■ Advanced anti-reverse power supply design to prevent damage from incorrect wiring
■ Built-in voltage stabilizer to ensure internal circuitry is unaffected by fluctuations in the car battery voltage
| Model: |
FH-4 Mini |
| Type: |
Class D Four Channels Amplifier |
| Max Power @ 4Ω: |
150 W x 4 ch |
| Nom Power @ 4Ω: |
100 W x 4 ch |
| Operating Voltage: |
8 - 18 VDC |
| Frequency Response: |
20 Hz - 20k Hz |
| Low Pass Frequency: |
40 Hz - 250 Hz |
| High Pass Frequency: |
40 Hz - 250 Hz |
| Signal Noise Ratio: |
101 dB |
| Distortion Degree(T.H.D.): |
≤0.01% |
| Input Sensitivity: |
0.5 V - 2 V |
| Input Impedance: |
10k Ω |
| Net Weight: |
1.2 kg |
| Dimensions (LxWxH;mm): |
206 x 140 x 48 |
