| ■ Hi-Fi transistor amplification circuit, capable of providing a 120W peak output (@4Ω) ■ 10Hz-70kHz (-3dB) frequency response, meeting the needs of various Hi-End speakers ■ Ultra-low distortion, with total harmonic distortion <0.02% ■ Servo power supply (high-low voltage H-class) design, enhancing the overall efficiency of the machine ■ Balanced heat dissipation system design, ensuring long-term stable operation ■ Gold-plated terminals, resistant to corrosion, oxidation, and durable for plugging and unplugging ■ Adopts TO-264 extra-large packaging audio-specific matched pairs ■ Ultra-compact size, Prussian blue painted aluminum alloy shell, with both aesthetics and heat dissipation performance ■ Multiple protections, suitable for various in-car usage environments |
| Model: | FM-1 |
| Type: | Class AB Mono Channel Amplifier |
| Max Power @ 2Ω: | 160 W |
| Nom Power @ 2Ω: | 80 W |
| Max Power @ 4Ω: | 120 W |
| Nom Power @ 4Ω: | 60 W |
| Freq. Resp. Range: | 10 Hz - 70 kHz(-3dB) |
| Signal Noise Ratio: | 96 dB |
| Input Impedance: | 22k Ω |
| Input Sensitivity: | 10 - 16 V DC |
| Degree Of Loss Of Truth: | <0.02 % |
| Net Weight: | 0.75 kg |
| Dimensions (LxWxH;mm): | 188 x 80 x 40 |
