■ 10 high-level inputs, 2 low-level inputs, optical, and Bluetooth 5.1 inputs
■ 10 low-level outputs, 12 high-level outputs
■ 31-band EQ adjustment
■ Class-AB + Class-D amplifier
■ High-quality electronic components
■ Full aluminum body for excellent heat dissipation
■ Computer tuning
■ Plug & play, lossless installation
| Model: |
FP-12AD |
| Type: |
10 ch DSP with 12 ch Amplifier |
| Power: |
DC 9 V～16 V |
| Input Signal Type: |
10 ch high level, 2 ch Low Level, Optical Fibre, Digital BT 5.1 |
| Dynamic Range: |
≥96 dB |
| S/N: |
≥96 dB |
| T.H.D.: |
≤0.01% |
| Frequency Response: |
20 Hz ~ 20k Hz |
| Decoding Capability: |
24 bit / 96k Hz |
| Max Power: |
50 W x 8 ch + 100 W x 4 ch |
| Nom Power: |
25 W x 8 ch + 50 W x 4 ch |
| Output Signal Type: |
10 ch Low Level Output, 12 ch High Level Output |
| Output Signal EQ: |
31 Levels EQ |
| Net Weight: |
1.48 kg |
| Dimension(LxWxH;mm): |
220 x 157 x 45 |
