| ■ 16-ch output, with 12-ch featuring power amplifier output ■ Ultra-compact size, easy to install ■ 31-band EQ adjustment, capable of saving 6 preset music scenes ■ Class-D high-power amplifier, capable of outputting 80Wx8ch + 160Wx4ch/BTL (300Wx1ch) ■ High-quality electronic components, delivering an ultimate sound quality experience ■ Full aluminum body, excellent heat dissipation ■ Plug & play, lossless installation |
| Model: | FP-12D |
| Type: | 16 ch DSP with 12 ch Amplifier |
| Power: | DC 9 V～16 V |
| Input Signal Type: | 10 ch high level, 2 ch Low Level, Optical Fibre, Digital BT 5.0, Coaxial |
| Dynamic Range: | ≥95dB |
| S/N: | ≥95dB |
| T.H.D.: | ≤0.05% |
| Frequency Response: | 20 Hz ~ 20k Hz |
| Decoding Capability: | 32 bit / 48k Hz |
| Max Power: | 80W x 8ch + 160W x 4ch/BTL(300W x 1ch) |
| Nom Power: | 40W x 8ch + 80W x 4ch/BTL(150W x 1ch) |
| Output Signal Type: | 16 ch Low Level Output, 12 ch High Level Output |
| Output Signal EQ: | 31 Levels EQ |
| Net Weight: | 2.5 kg |
| Dimension(LxWxH;mm): | 260.5 x 190 x 46 |
