■ 16-Channel Professional Pure DSP
■ Hi-End Decoding Chip with Ultra-High Computational Power
■ ADI's ADAU1977 High-Performance ADC Professional Chip
■ Qualcomm's QCC5171 BT 5.3 High-Definition Audio Transmission
■ ADI's ADAU1966 High-Performance Low-Distortion Audio DAC Decoding Chip
■ Ultra-High Dynamic Range, Supports High Resolution, and Multiple Sampling Rates
■ Wide Voltage Adaptive Technology, Supports Input Voltage from 10-26V
■ Plug and Play, Seamless Installation
| Model: |
FP-16 Pure |
| Type: |
16-Ch Professional Digital Signal Process |
| Power: |
DC 10V～26 V |
| Input Signal Type: |
16 ch high level, AUX, Optical Fibre, Digital BT, Coaxial |
| Dynamic Range: |
≥114 dB |
| S/N: |
≥116 dB |
| T.H.D.: |
≤0.0018% |
| Frequency Response: |
10 Hz ~ 44k Hz |
| Decoding Capability: |
24bit/44.1kHz/48kHz/96kHz/192kHz |
| Output Signal Type: |
16 ch Low Level Output |
| Output Signal EQ: |
31 Levels EQ |
| Net Weight: |
1.53 kg |
| Dimension(LxWxH): |
222 x 210 x 46 mm |
