■ Class D power amplifier.
■ PCB board made of high-strength flame-retardant fiberglass material.
■ Ultra-high power, capable of driving two subwoofers.
■ Internal bridge design for increased output power.
■ Gold-plated terminals: corrosion-resistant, oxidation-resistant, durable for repeated connections.
■ Compact size with all-aluminum chassis for efficient heat dissipation.
■ Built-in voltage regulator ensures internal voltage remains unaffected by vehicle battery voltage fluctuations.
■ Multiple protection features suitable for various in-vehicle environments.
■ Can be connected to a remote control panel (control panel is optional accessory).
| Model: |
FS-1 V2 |
| Type: |
Class D Mono Channel Amplifier |
| Max Power @ 1Ω: |
2600 W |
| Nom Power @ 1Ω: |
2500 W |
| Max Power @ 2Ω: |
2250 W |
| Nom Power @ 2Ω: |
1500 W |
| Max Power @ 4Ω: |
1350 W |
| Nom Power @ 4Ω: |
900 W |
| Freq. Resp. Range: |
10 Hz - 400 Hz |
| Lo-Pass Freq. Adju.: |
50 Hz - 400Hz |
| Signal Noise Ratio: |
≥100 dB |
| Input Impedance: |
20k Ω |
| Input Sensitivity: |
0.293 V, 0.87 V, 7.3 V |
| Operating Voltage: |
9 - 17 V DC |
| Degree Of Loss Of Truth: |
0.02 % |
| Net Weight: |
3.97 kg |
| Dimensions (LxWxH): |
319 x 190 x 50 mm |
